SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization

SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization
SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization
Basic Information
Place of Origin: China
Brand Name: YL
Model Number: YEDU-1B
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: 1-2 plywood case
Delivery Time: around 45-55 working days
Payment Terms: T/T,Western Union,D/P,D/A,Western Union,MoneyGram
Supply Ability: 1 set per 45 days
Get Best Price
Chat Now
Detail Information
Model NO.: YEDU-1B Print Head And Max. Printing Width: SEIKO 72mm Black Ink (or White Ink).
Origin: China Ambient Temperature: 0-40degree
Compressed Air: 6KG/CM2,10L/min. Transport Package: Transport Package
Dimesion: Around L(2300/4300/5600mm)×W650mm×H1600 Mm Weight: About 500-950kgs
Highlight:

72mm DOD Card printer

,

54mm DOD Card printer

,

36mm DOD Card printer

Product Description

Drop On Demand Inkjet DOD Card Printer 36mm 54mm 72mm Printing Length Card DOD Personalization Line YEDU-1B
Attribute Value
Model NO. YEDU-1B
Print head and Max. printing width SEIKO 72mm black ink (or white ink)
Origin China
Ambient Temperature 0-40°C
Compressed air 6KG/CM², 10L/min
Transport Package Standard transport packaging
Dimension L(2300/4300/5600mm) × W650mm × H1600mm
Weight 500-950kg
SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization 0
The Card DOD Personalization Machine YEDU-1B is designed for high-quality personalization of various smart cards including loyalty cards, magnetic cards, RFID cards, and dual-interface cards. It features:
  • DOD (drop-on-demand) inkjet printing
  • RFID chip encoding (optional)
  • Magnetic stripe encoding (optional)
  • Scratch card labeling (optional)
  • Laser engraving unit (optional)
Ideal for financial cards, social security cards, and membership cards, with functions including magnetic stripe encoding, contactless encoding, double side DOD printing, and OCR detection.
Technical Specifications
Parameter Value
Throughput 10,000 cards/h (print-only mode)
Standard card size 85.6×54×(0.5-0.8)mm
Total Power 6KW
Power Supply AC 220V, 50/60Hz
Working temperature 0-40°C
Compressed air supply 0.6-0.8 MPA
Working relative humidity 15-90%
Optional Functional Modules
RFID Chip Encoding Unit (HF/LF)
Reads UID from most RFID card chips in the market. Writing speed: 2,000-4,000 cards/hour depending on data size.
Magnetic Stripe Encoder
Encodes three tracks or any single/two tracks in magnetic cards (excluding financial bank cards) at 7,000-8,000 cards/hour.
OCR Inspection Unit
Verifies printed numbers, barcodes, and QR codes against database at 7,000-8,000 cards/hour.
Scratch Labeling Unit
Applies multiple scratch-off labels simultaneously at 7,000-8,000 cards/hour.
Laser Engraving Unit
Available in CO2, optical fiber, or ultraviolet types for precise marking of serial numbers, logos, and QR codes.
Key Performance Parameters
  • Print head: SEIKO 72mm black/white ink
  • Printing resolution: 360-720 DPI adjustable
  • Max printing speed: 25 meters/min
  • Optimal quality speed: 20 meters/min
  • LED UV: 395NM, 400W
  • Control: Industrial computer + motion control system
  • Weight: 500-950kg (configuration dependent)
SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization 1
System Features
  • Full financial card personalization capabilities
  • High-resolution DOD printing with durable, lightfast results
  • Modular design for flexible configuration
  • Includes SDK and DLL for custom software development
  • Available in 36mm (YEDU-1A) or 72mm (YEDU-1B) print widths
SEIKO 72mm Drop On Demand Inkjet DOD Card Printer For Smart Card Personalization 2
