Name: Grained Finish Smart Card Consumables Card Lamination Aluminum Plate 25 - 35HV Hardness
Brand: YL Electrical Equipment (Tianjin) Co., Ltd.
SKU: YAP-G
Availability: InStock

Detail Information

Plate Size(L×W):	A4, A3 Or Custom-made Size	Plate Thickness:	1.0mm (Thickness Tolerance: ±0.05mm)
Dimension Tolerance:	±1mm For Length And Width.	Plate Flatness Level:	Maximum 1 Mm.m
Surface Roughness Value Range:	2.1-5.5um	Surface Hardness:	25-35HV
Highlight:	Grained Finish Smart Card Consumables , Smart Card Consumables 35HV , Card Lamination Aluminum Plate

Product Description

Grained Finish Card Lamination Aluminum Plate with 25-35HV Surface Hardness

Product Specifications

Attribute	Value
Plate size(L×W)	A4, A3 or custom-made size
Plate thickness	1.0mm (Thickness tolerance: ±0.05mm)
Dimension tolerance	±1mm for length and width
Plate flatness level	maximum 1 mm.m
Surface roughness value range	2.1-5.5um
Surface hardness	25-35HV

card lamination aluminum plate, laminator aluminum plate, textured laminating steel plate, special pattern lamination plate, card finish Grained lamination plate, card production material

Product Overview

Our 2.1-5.5um Value Range 25-35HV Surface Hardness Grained Finish Card Lamination Aluminum Plate (YAP-G) serves as essential consumables in plastic card lamination, ensuring perfect surface finish. Widely used by card manufacturers globally, these plates deliver consistent quality results.

Key Features

Both sides feature protective blue films that leave no residue when removed
Consistent grained finish quality on both surfaces
Free from scratches, dents, stripes, shadows, and dust
Smooth, deburred edges with rounded corners
Non-stick surface prevents adhesion to laminated plastic sheets

Technical Parameters

Packaged in solid plywood cartons with soft cushion protection for secure transportation.

Applications

Manufactured from premium imported steel, our plates offer excellent heat conductivity, pressure resistance, and high-quality mirror finish. With over a decade of industry experience, we supply superior quality plates that meet international card production standards.

Available Steel Plate Varieties

Glossy/Mirror finish: Standard mirror effect for planographic and inkjet coding
Fine matte (Ra:0.25-0.5um): Thin, lubricious surface with tiny lights
Coarse matte (Ra:1.0-2.0um): Heavy texture unsuitable for planographic coding
Silk-Satin finish: Moderate coarse surface for RFID inlay production
Pattern steel plates: Various surface patterns available

Tag:

Place of Origin:	China
Brand Name:	YL
Model Number:	YAP-G

Minimum Order Quantity:	100PCS
Price:	negotiable
Packaging Details:	1 plywood case based on order qty and size
Delivery Time:	10-15days after receiving the prepayment
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	10000PCS per 10days
