Name: Semi Matte Card Lamination Plate 0.6mm - 1.0mm For Smart Card Production
Brand: YL Electrical Equipment (Tianjin) Co., Ltd.
SKU: YSP-M
Availability: InStock

Detail Information

Plate Size(L×W):	A4, A3 Or Custom-made Size	Plate Thickness:	0.6mm, 0.8mm 1.0mm (Thickness Tolerance: ±0.05mm)
Dimension Tolerance:	±1mm For Length And Width.	Plate Flatness Level::	Maximum 1 Mm.m
Surface Roughness:	Matte Plate (Ra=0.3μm - 2.0μm)	Glossy Plate Surface Glossiness:	Over 800 GU At 20° (both Sides)
Highlight:	Semi Matte Card Lamination Plate , Card Lamination Plate 1.0mm , Smart Card Lamination Plate

Product Description

Semi Matte Card Lamination Plate Smart Card Production Consumables 0.6-1.0mm Thick

Product Specifications

Attribute	Value
Plate size(L×W)	A4, A3 or custom-made size
Plate thickness	0.6mm, 0.8mm 1.0mm (Thickness tolerance: ±0.05mm)
Dimension tolerance	±1mm for length and width
Plate flatness level	maximum 1 mm.m
Surface roughness	Matte plate (Ra=0.3μm - 2.0μm)
Glossy plate surface glossiness	over 800 GU at 20° (both sides)

Product Description

0.6-1.0mm Thick Semi Matte Card Lamination Plate YSP-M For Smart Card Production

semi matte card lamination plate, heavy matte laminating steel plate, matte plate for card laminator, card finish lamination plate, card production material

Product Introduction

These plates are essential consumables for plastic card lamination, ensuring perfect surface finish on laminated cards. Widely used by card manufacturers globally, our plates meet the highest quality standards.

Key Features

Both sides feature protective foils (blue thin films) that leave no residue when removed
Consistent quality on both glossy and matte surfaces
Free from scratches, dents, stripes, shadows, and dust
Smooth edges with rounded, deburred corners
Non-stick surface prevents adhesion to laminated plastic sheets

Technical Parameters

Plate size(L×W)	A4, A3 or custom-made size
Plate thickness	0.6mm, 0.8mm (Thickness tolerance: ±0.05mm)
Dimension tolerance	±1mm for length and width
Plate flatness level	maximum 1 mm.m
Surface roughness	Matte plate (Ra=0.3μm - 2.0μm)
Glossy plate surface glossiness	over 800 GU at 20° (both sides)
Surface hardness	HRC80±20
Thermal transmission	0.04cal/℃.cm.sec at 20℃
Packaging	Solid plywood carton with soft cushion protection

Applications

Also known as semi matte finish plastic card laminating plate or heavy matte lamination steel plate, this product is essential for professional card production.

Tag:

Place of Origin:	China
Brand Name:	YL
Model Number:	YSP-M

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	1 plywood case based on ordered qty and size
Delivery Time:	10-15days after receiving the prepayment
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	1 set per 10-15 days
