Name: 10.5KW Full Auto Smart Card Punching And Sorting Machine E Eye Positioning 8x7 Layout
Brand: YL Electrical Equipment (Tianjin) Co., Ltd.
SKU: YLP-FAS-1000
Availability: InStock

Detail Information

Layout Sheet:	3x8,4x8,x7x8,5x5 Etc	Control Method:	Servo System + PLC
Total Power:	About 10.5KW	Weight:	About 1800Kg
Feeding Height:	Max 600 Mm	Card Numbers In The Card Slot:	About 400pcs Cards
Highlight:	10.5KW Card Punching Machine , Card Sorting Machine 8x7

Product Description

10.5KW Full Auto Smart Card Punching And Sorting Machine E Eye Positioning 8x7 Layout

Product Specifications

Attribute	Value
Layout sheet	3x8, 4x8, 7x8, 5x5 etc
Control method	Servo system + PLC
Total Power	About 10.5KW
Weight	About 1800Kg
Feeding height	Max 600 mm
Card numbers in the card slot	About 400pcs cards

Product Overview

Full-Auto Smart Card Punching and Sorting E-eye Positioning 8x7 layout YLP-FAS-1000

This advanced machine automates plastic card punching with high-efficiency collection and sorting. Controlled by PLC with bilingual (Chinese/English) touch screen interface, it ensures precise operation through electrical eye positioning to prevent sheet deviation.

Key Features

Electrical eye positioning with adjustable parameters for high precision
High-power servo motor for quiet, fast, and stable operation with adjustable speed
Advanced card sorting structure with adjustable positioning for reliable operation
Automatic collection and sorting by printed pattern layout
PLC-controlled operation with real-time monitoring and automatic shutdown

Technical Parameters

Power Supply	AC 380V/50 HZ
Applicable Layout	5X5, 4X8, 6X8, 8X8
Total Power	10.5KW
Control mode	PLC program control + servo system
Air Source	6 kg/c㎡ (with no water)
Operator number	One person
Air consumption	About 150L/min
Dimension	L2600×W1240×H1750mm
Weight	About 1800Kg
Punched card standard	ISO CR-80-ISO7810
Productivity	800~1000 big sheets/hour
Punching precision	±0.10mm
Applicable Material	PVC, ABS, PET, PETG, paperboard, and mixed materials
Collecting height	Max 700 mm

Machine Characteristics

This integrated system features automatic sheet feeding, punching, card output, and waste collection for standard smart cards. Equipped with multiple punching heads for simultaneous operation and automatic card sorting. Includes code scanning function to record sheet materials during processing.

Tag:

Place of Origin:	China
Brand Name:	YL
Model Number:	YLP-FAS-1000

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	Standard export plywood case
Delivery Time:	around 30-40days
Payment Terms:	T/T, Western Union, D/P, D/A, Western Union
Supply Ability:	5 sets per quater
