Name: Auto Plastic Playing Card Punching Machine 5x5 Card Die Cutter YLP-FA-600
Brand: YL Electrical Equipment (Tianjin) Co., Ltd.
SKU: YLP-FA-600
Availability: InStock

Detail Information

Suitable Material:	PVC, ABS, PET, PETG, Paper Card, PVC And ABS Mixed Materials, Etc.	Speed:	6000~16000 Cards /hour
Control Method:	PLC Program Control + Servo System	Punching Precision:	±0.10mm
Air Source:	6 Kg/c㎡(with No Water)	Applicable Layout:	2x5, 3x8, 4x8 Or 5x5 Layout
Highlight:	Card Punching Machine 5x5 , PET Card Punching Machine , 5x5 Card Die Cutter

Product Description

Auto Plastic Playing Card Punching Machine 5x5 Card Die Cutter YLP-FA-600

Key Specifications

Suitable Material	PVC, ABS, PET, PETG, paper card, PVC and ABS mixed materials
Speed	6000~16000 cards/hour
Control method	PLC program control + servo system
Punching precision	±0.10mm
Air Source	6 kg/c㎡ (with no water)
Applicable layout	2x5, 3x8, 4x8 or 5x5 layout

Product Overview

This economic automatic card puncher features compact structure, reliable performance, and full automatic operation. Controlled by PLC program with Chinese/English bilingual touch screen interface for user-friendly operation.

Key Features

Servo motor driven feeding and conveying system with adjustable material positioning
High-precision ball screw module for precise punching feed with adjustable parameters
High-power servo motor provides low noise, fast speed, and stable punching power
PLC program control with real-time monitoring and automatic shutdown for abnormal situations
High-sensitivity laser sensor and stepping system for accurate longitudinal positioning

Technical Parameters

Power supply	AC 380V/50 HZ
Power	6.5KW
Air consumption	About 100L/min
Weight	About 1000Kg
Punched card standard	Complies with ISO CR-80-ISO7810 international standard
Dimension	L1600×W1250×H1650mm

Packaging & Service

Standard export packaging with PE film protection inside and plywood case outside.

Comprehensive Service Support

Pre-sale: Professional suggestions, device model selection, feasibility analysis
Sale: Quality supervision, product acceptance, timely shipping
After-sale: Installation guidance, operator training, lifetime technical support

Warranty

1-year guarantee period with efficient service support. On-site assistance available for unsolvable technical issues within warranty period.

Tag:

Place of Origin:	China
Brand Name:	YL
Model Number:	YLP-FA-600

Minimum Order Quantity:	1 set
Price:	negotiable
Packaging Details:	Standard export plywood case
Delivery Time:	25-30days
Payment Terms:	T/T,Western Union,MoneyGram,Western Union
Supply Ability:	5 sets per quater
